Southwire Company Southwire 22956701 THHN 14 Gauge Building Wire - Stranded Type, White, 500 ft

Description

Available in black, white, red, blue, purple, green, yellow, brown, orange, and gray. This cable may be installed without the need for pulling lubricant. VW-1 - Sizes 14 through 1 AWG CT - UL 1685, Sizes 1/0 AWG and larger for CT use. Conductor temperatures not to exceed 105 C in dry locations when rated AWM and used as appliance wiring material or when used asT90 Nylon. Specifications: Southwire SIMpull THHN or THWN-2 or MTW (also AWM) meets or exceeds all applicable ASTM specifications, UL Standard 83, UL 1581, UL Standard 1063 (MTW), CSA, NOM-ANCE 90 C, Federal Specification A-A-59544, and requirements of the National. Voltage for all applications is 600 volts. Some colors standard, some subject. When used as Type MTW, conductor is suitable for use in wet locations or when exposed to oil at temperatures not to exceed 60 C or dry locations at temperatures not to exceed 90 C (with ampacity limited to that for 75 C conductor temperature per NFPA 79). Construction: Southwire SIMpull THHN or THWN-2 or MTW copper conductors are annealed (soft) copper, unilay compressed strand, insulated with a tough heat and moisture resistant polyvinyl chloride (PVC), over which a SIM (SLIKQWIK Infused Membrane) nylon. THHN 14 Gauge Building Wire, Stranded Type, White Applications: Southwire SIMpull THHN or THWN-2 conductors are primarily used in conduit and cable trays for services, feeders, and branch circuits in commercial or industrial applications as specified in the.

Key Features

• When used as Type THWN-2 or TWN75, conductor is suitable for use in wet or dry locations at temperatures not to exceed 90 C or not to exceed 75 C when exposed to oil.
• When used as Type MTW, conductor is suitable for use in wet locations or when exposed to oil at temperatures not to exceed 60 C or dry locations at temperatures not to exceed 90 C (with ampacity limited to that for 75 C conductor.
• Conductor temperatures not to exceed 105 C in dry locations when rated AWM and used as appliance wiring material or when used asT90 Nylon.
• VW-1 - Sizes 14 through 1 AWG CT - UL 1685, Sizes 1/0 AWG and larger for CT use.
• FT1 - Sizes through 500 kcmil T90 Nylon - Sizes through 500 kcmil TWN 75 - Sizes through 500 kcmil RoHS Compliant Sunlight Resistant - Marked and listed in all colors 2 AWG and larger.
• When used as Type THHN, or T90 Nylon conductor is suitable for use in dry locations at temperatures not to exceed 90 C.
